GRM carries a wide range of valve parts for Model F and FC for either manual or hydraulic gate valves. All parts are manufactured to meet or exceed the rigorous standard set for API 6A wellhead equipment.
Our world-class, precision machined parts interchange with major OEM brands and are available in 2-1/16″ through 4-1/16″ bore sizes and in 2,000 to 15,000 PSI pressure ratings.
| # | Description | QTY | Material | 4 1/16" 5,000 PSI |
4 1/16" 10,000 PSI |
4 1/16" 15,000 PSI |
|---|---|---|---|---|---|---|
| 1 | Handwheel | 1 | - | POR | POR | POR |
| 2 | Bearing Cap | 1 | - | VCIW1845 | VCIW1846 | POR |
| 3 | Grease Fitting | 2 | Zinc Plated | VCIW1940 | VCIW1940 | VCIW1940 |
| 4 | O-Ring | 1 | Nitrile 70D | VCIW2000 | VCIW2000 | VCIW2005 |
| 5 | Bearing Race | 4 | Alloy | VCIW2060 | VCIW2070 | VCIW2072 |
| 6 | Bearing | 2 | Alloy | VCIW2040 | VCIW2050 | VCIW2052 |
| 7 | O-Ring (Stem Adapter) |
1 | Nitrile 70D | VCIW2020 | VCIW2025 | POR |
| 8 | Stem Adapter | 1 | Alloy | VCIW1840 | VCIW1841 | VCIW1842 |
| 9 | Stem Pin | 1 | 1045 CS | VCIW2080 | VCIW2085 | VCIW2090 |
| 10 | Packing Gland | 1 | Alloy | VCIW1860 | VCIW1861 | VCIW1863 |
| 11 | Stem Packing | 1 | PTFE/BUNA | VCIW1000 | VCIW1040 | VCIW1045 |
| 12 | Nut | 8 | - | POR | POR | POR |
| 13 | Stud | 8 | - | POR | POR | POR |
| 14 | Bonnet | 1 | - | POR | POR | POR |
| 15 | Check Valve | 1 | 316 SS | FI207620 | FI207620 | FI207620 |
| 16 | Grease Fitting | 1 | 316 SS | FA400520 | FA400520 | FA905220 |
| 17 | Bonnet Gasket | 1 | 304SS 316 SS |
VCIW1480 N/A |
VCIW1494 N/A |
N/A VCIW1498 |
| 18 | Gate/Seat Assembly | 1 | - | POR | POR | POR |
| 19 | Stem | 1 | 17-4 SS | VCIW1640 | VCIW1656 | VCIW1658 |
| 20 | F/FC Gate | 1 1 1 |
4130 Nitrided 410 SS Nitrided 4130 HF#5 |
VCIW1102 POR VCIW1168 |
VCIW1110 VCIW1178 VCIW1170 |
POR POR VCIW1186 |
| 20 | JMP Style Gate | 1 | 4130 HF #5 | N/A | N/A | VJMP1000 |
| 21 | Retainer Plate | 2 | 1018 CS | VCIW1560 | VCIW1570 | VCIW1575 VCIW1575-X |
| 22 | Seat | 2 | Stellite #6 | VCIW1330 | VCIW1340 | VCIW1375 |
| 23 | Seat Seal | 2 | GF/PTFE | VCIW1240 | VCIW1240 | VCIW1248 |
| 24 | Pin | 2 | - | POR | POR | POR |
| 25 | Body | 1 | - | POR | POR | POR |
| 26 | Name Plate | 1 | - | POR | POR | POR |
| 27 | Body Bushing Seal |
2 | GF/PTFE | VCIW1820 | VCIW1820 | VCIW1821 |
| 28 | Body Bushing | 2 | 410 SS | VCIW1730 | VCIW1740 | VCIW1755 |
| 29 | Gate Guide | 2 | 304 SS | VCIW1930 | VCIW1935 | VCIW1936 |
