Boasting a worldwide reputation that was founded in chemical plant, refinery, wellhead and pipeline service, GRM’s high pressure hydraulic grease gun is second-to-none in reliability, durability and user-friendliness. Lightweight and rugged, The SNIPER™ hydraulic hand gun has set the standard in every extreme condition you can imagine. Customize our tool for any industrial-rated need with universal adapters, couplers and hoses.
| # | DESCRIPTIOn | PART # |
|---|---|---|
| Grease Gun, Hydraulic | GG255000 | |
| 1 | Handle with Knob | GG255220 |
| 2 | Fulcrum Assembly | GG255225 |
| 3 | Linkage Assembly | GG255230 |
| 4 | Body | GG255235 |
| 5 | Hydraulic Pump Cylinder w/ “O” Ring | GG255240 |
| 6 | “O” Ring (Piston Seal) | GG255245 |
| 7 | “O” Ring (Top of Pump Cylinder) | GG255250 |
| 8 | “O” Ring (Bottom of Pump Cylinder) | GG255255 |
| 9 | Pump Piston | GG255260 |
| 10 | Check Valve Assembly | GG255265 |
| 11 | By-Pass Valve with “O” Ring | GG255270 |
| 12 | “O” Ring (By-Pass Valve) | GG255275 |
| 13 | By-Pass Valve Stop | GG255280 |
| 14 | By-Pass Valve Stop Screw | GG255285 |
| 15 | Internal Relief Valve | GG255290 |
| 16 | “O” Ring (By-Pass Valve) | GG255295 |
| 17 | Hydraulic Fluid Bag with Bleeder | GG255300 |
| 18 | Hydraulic Fluid Bag Seal Ring | GG255305 |
| 19 | Hydraulic Fluid Bag Barrel | GG255310 |
| 20 | Hydraulic Fluid Bag Barrel Cap | GG255315 |
| 21 | Grease Barrel | GG255320 |
| 22 | “O” Ring Grease Barrel | GG255325 |
| 23 | Grease Barrel Cap | GG255330 |
| 24 | Piston Assembly | GG255335 |
| 25 | Washer Nut (2) | GG255340 |
| 26 | Leather Cup (2) | GG255345 |
| 27 | Piston | GG255350 |
| 28 | “O” Ring (Piston Body) | GG255355 |
| 29 | Piston Cap Screw (2) | GG255360 |
| 30 | “O” Ring (Piston Cap Screw) | GG255365 |
| 31 | Giant Button Head Coupler | FT706610 |
| 32 | Hose with Swivel | GG255375 |
| 33 | 15, 000 PSI Gauge with Adapter | GG255380 |
| 34 | Plunger | GG255385 |
| DESCRIPTION | PART # |
|---|---|
| Hydraulic Hand Held, High Pressure Grease Gun | GG255000 |
| Major Repair Kit | GG255990 |
| DESCRIPTION | PART # |
|---|---|
| 2 1'2" Gauge, 15,000 PSI | GG155305 |
| Adapter Tee | GG155310 |
| Straight Swivel | GG155335 |
| 90 Swivel | GG155330 |
| Z Swivel | GG155325 |
